LUXONIS OAK-FFC-OV9782-M12 (22 pin) carrier board for OV9282 camera module, compatible with OAK-FFC-3P, OAK-FFC-4P, and DepthAI RPi HAT baseboards

$143.00

Availability: In stock

SKU: A00445

Qty:
'The OAK-FFC-OV9782-M12 is a carrier board for the mono global shutter OV9282 camera module, and is designed to be compatible with OAK-FFC-3P, OAK-FFC-4P, and DepthAI RPi HAT baseboards. In many applications, great color representation and the capability to digitally zoom is very important. So DepthAI was designed with this in mind to provide the option to have high-resolution, accurate color representation at high frame rates to boot. Camera Specifications: Sensor: Color global shutter OV9782 Pixel Size: 3 μm x 3 μm Active array size: 1280 x 800 Optical Size: 1/4 inch Focusing Range: 20cm ~ infinite IR Sensitive: With IR filter, sensitive to Visible light Output interface: MIPI 2-Lane Output formats: RAW8/RAW10 Maximum image transfer rate: 1280 x 800@120 fps Lens: Default low distortion M12 lens (Part Number: M27280M07S) EFL: 2.8mm F.N: 2.8 HFOV: 75 Deg Board Size: 24x25mm'
